7. July 2026
further reading
Schematics Placement
Target Project File
Source Code
Target 3001 Website HMC363S8G ADF4113HV ATtiny13 BFR 92 AYOUR OPINION •••
average: 8.667, n: 3
When using this form, your ip is stored in order to avoid multiple voting on the same website. That's it.
When using this form, your ip is stored in order to avoid multiple voting on the same website. That's it.
prescaler_12GHz.php 5161 Bytes 04-03-2025 19:13:23
ELECTRONIC PROJECTS : CETH-60
12 GHz Prescaler :1000
The Prescaler is a handy Accessories to extend the Frequency Range of any Counter to 12 GHz.
The Use of a HMC363 in alliance with a PLL (ADF4113HV) and a ATtiny13™ allows a division rate of 1000.
Easy Reading assured !
The Input Voltage range is about - 20 dBm to + 10 dBm.
Circuit Description
The first stage is a HMC363SG8 which divides the input signal by 8. The next stage is a PLL-IC (ADF4113HV) which is
cheap and has the the ability of output the RF_IN divided by the Prescaler/Counter, which is set by an ATtiny 13
to 125.
A final Buffer (BFR92) decouples and amplifies this signal so that a Counter can count it.
A final Buffer (BFR92) decouples and amplifies this signal so that a Counter can count it.
✈ Share your thoughts
The webmaster does not read these comments regularely. Urgent questions should be send via email.
Ads or links to completely uncorrelated things will be removed.
|
t1 = 7299 d
t2 = 339 ms |
★ ★ ★ Copyright © 2006 - 2026 by changpuak.ch ★ ★ ★
|
|
